SPECIFICATIONS
Category |
Feature |
Specification |
Credential |
Biometric |
Fingerprint |
RF Option |
BER2-OD: 125kHz EM & 13.56MHz MIFARE, MIFARE Plus, DESFire/EV1, FeliCa, NFC |
|
RF read range* |
MIFARE/DESFire/EM: 50mm, FeliCa: 30mm
* RF read range will vary depending on the installation environment. |
|
General |
CPU |
1.0GHz |
Memory |
32MB Flash + 32MB RAM |
|
LED |
Multi-color |
|
Sound |
Buzzer |
|
Operating temperature |
-20°C ~ 50°C |
|
Storage temperature |
-40°C ~ 70°C |
|
Operating humidity |
0% ~ 80%, non-condensing |
|
Storage humidity |
0% ~ 90%, non-condensing |
|
Dimension (W x H x D) |
50 mm x 164 mm x 37.5 mm |
|
Weight |
Device: 158g |
|
Bracket: 39g (Including washer and bolt) |
||
Certificates |
CE, FCC, KC, RoHS, REACH, WEEE |
|
Fingerprint |
Image dimension |
272 x 320 pixels |
Image bit depth |
8bit, 256 grayscale |
|
Resolution |
500 dpi |
|
Template |
SUPREMA / ISO 19794-2 / ANSI 378 |
|
Interface |
RS-485 |
1ch slave (OSDP V2 Compliant) |
Tamper |
Supported |
|
Electrical |
Power |
Voltage: DC 12V |
Platform |
BioStar 2 |
Supported |
