Specifications
|
Category |
Feature |
FSF2-ODB |
FSF2-DB |
FSF2-AB |
|
|
Credential |
Biometric |
Face, Fingerprint |
Face |
||
|
RF Option |
125kHz EM & 13.56MHz MIFARE, MIFARE Plus, DESFire EV1/EV2, FeliCa |
125kHz EM & 13.56MHz MIFARE, MIFARE Plus, DESFire EV1/EV2, FeliCa, iCLASS SE/SR/Seos |
|||
|
RF read range* |
EM/MIFARE/DESFire : 50 mm (2"), FeliCa: 30 mm (1.2") |
||||
|
Mobile |
NFC, BLE |
||||
|
General |
CPU |
1.8 GHz Dual Core + 1.4 GHz Quad Core |
|||
|
Memory |
16GB Flash + 2GB RAM |
||||
|
LCD type |
7” IPS color LCD |
||||
|
LCD resolution |
800 x 1280 pixels |
||||
|
Sound |
16bit |
||||
|
Operating temperature |
-20°C ~ 50°C (-68°F ~ 122°F) |
||||
|
Operating humidity |
0% ~ 80%, non-condensing |
||||
|
Dimension (W x H x D) |
119.8mm x 268.4mm x 49.7mm |
119.8mm x 223mm x 23.5mm |
|||
|
Weight |
Device |
670g |
585g |
||
|
Bracket (Including washer and bolt) |
205g |
181g |
|||
|
IP rating |
IP65 |
||||
|
Certificates |
CE, FCC, KC, RoHS, REACH, WEEE |
||||
|
Face |
Recognition Distance |
0.5cm ~ 1.3m (19.7" ~ 51.2") |
|||
|
Recognition Height |
140cm ~ 190cm (55.1" ~ 74.8") |
||||
|
Matching speed |
Less than 0.5 sec |
||||
|
Anti-Spoofing |
Supported |
||||
|
Fingerprint |
Image dimension |
300 x 400 pixels |
N/A |
||
|
Resolution |
500 dpi |
||||
|
Template |
SUPREMA / ISO19794-2, ANSI-378 |
||||
|
Extractor / Matcher |
MINEX certified and compliant |
||||
|
Sensor Certificates |
FBI PIV and FBI Mobile ID FAP20 |
||||
|
Live Fingerprint Detection |
Supported (SW-based) |
||||
|
Fingerprint |
Max. User (1:1) |
100,000 |
|||
|
Max. User (1:N) |
Face: 50,000 |
Face: 50,000 |
|||
|
Max. Text Log |
5,000,000 |
||||
|
Max. Image Log |
50,000 |
||||
|
Interface |
Ethernet |
Supported (10/100 Mbps, auto MDI/MDI-X) |
|||
|
RS-485 |
1ch Host or Slave (Selectable) |
||||
|
Wiegand |
1ch Input, 1ch Output |
||||
|
TTL input |
2ch Inputs |
||||
|
Relay |
1 Relay |
||||
|
USB |
USB 2.0 (Host) |
||||
|
Tamper |
Supported |
||||
|
Power |
Voltage: DC 12V ~ DC 24V |
||||
