SPECIFICATIONS
|
Category |
Feature |
Specification |
|
Credential |
Biometric |
Face |
|
RF Option |
FS2-D: 125kHz EM & 13.56MHz MIFARE, MIFARE Plus, DESFire/EV1, FeliCa, NFC |
|
|
FS2-AWB: 125kHz EM, HID Prox & 13.56MHz MIFARE, MIFARE Plus, DESFire/EV1, FeliCa, iCLASS SE/SR, NFC & 2.4 GHz BLE |
||
|
RF read range |
MIFARE/DESFire/iCLASS : 50 mm, EM/HID Prox/Felica: 30 mm, BLE: 50 mm
* RF read range will vary depending on the installation environment. |
|
|
General |
CPU |
1.4 GHz Quad Core |
|
Memory |
8GB Flash + 1GB RAM |
|
|
LCD type |
4” color TFT LCD |
|
|
LCD resolution |
800 x 480 pixels |
|
|
IR LED |
140 ea (940 nm) |
|
|
Sound |
24 bit/Voice DSP (echo cancel) |
|
|
Operating temperature |
-20°C - 50°C |
|
|
Storage temperature |
-40°C - 70°C |
|
|
Operating humidity |
0% - 80%, non-condensing |
|
|
Storage humidity |
0% - 90%, non-condensing |
|
|
Camera type |
CMOS |
|
|
Camera resolution |
720 x 480 pixels |
|
|
Camera angle |
Visual Lens : Diagonal 92.7°, IR Lens : Diagonal 58° |
|
|
Dimension (W x H x D) |
141 x 164 x 125 (mm) |
|
|
Weight |
Device: 548g |
|
|
Bracket: 74g (Including washer and bolt) |
||
|
Certificates |
CE, FCC, KC, RoHS, REACH, WEEE, BT SIG
* BT SIG is applied to only FS2-AWB model. |
|
|
Fingerprint |
Image dimension |
720 x 480 pixels |
|
Image bit depth |
8bit, 256 grayscale |
|
|
Template |
SUPREMA |
|
|
Live face detection |
Supported |
|
|
Capacity |
Max. User (1:1) |
30,000 |
|
Max. User (1:N) |
3,000 |
|
|
Max. Template (1:1) |
900,000 |
|
|
Max. Template (1:N) |
90,000 |
|
|
Max. Text Log |
5,000,000 |
|
|
Max. Image Log |
50,000 |
|
|
Interface |
Wi-Fi |
Supported (Built-in, IEEE 802.11 b/g)
* Wi-Fi is applied to only FS2-AWB model. |
|
Ethernet |
Supported (10/100/1000 Mbps, auto MDI/MDI-X) |
|
|
RS-485 |
1ch Host or Slave (Selectable) |
|
|
Wiegand |
1ch Input, 1ch Output |
|
|
TTL input |
2ch Inputs |
|
|
Relay |
1 Relay |
|
|
USB |
USB 2.0 (Host) |
|
|
Tamper |
Supported |
|
|
Electrical |
Power |
Voltage: DC 24V |
|
Switch input VIH |
Min. 3V |
|
|
Switch input VIL |
Max. 1V |
|
|
Switch Pull-up resistance |
4.7kΩ (The input pots are pulled up with 4.7kΩ.) |
|
|
Wiegand output VOH |
More than 4.8V |
|
|
Wiegand output VOL |
Less than 0.2 V |
|
|
Wiegand output Pull-up resistance |
Internally pulled up with 1 kΩ |
|
|
Relay |
Voltage: Max. 30VDC |
|
|
Platform |
BioStar 2 |
Supported |
|
BioStar 1 |
Not Supported |
