SPECIFICATIONS
|
Category |
Feature |
Specification |
|
Credential |
Biometric |
Fingerprint |
|
RF Option |
BSA2-OEPW: 125kHz EM |
|
|
BSA2-OHPW: 125kHz HID Prox |
||
|
BSA2-OIPW: 13.56MHz MIFARE, MIFARE Plus, DESFire/EV1, FeliCa, iCLASS SE/SR, NFC |
||
|
BSA2-OMPW: 13.56Mhz MIFARE, MIFARE Plus, DESFire/EV1, FeliCa, NFC |
||
|
RF read range* |
MIFARE: 50 mm, DESFire: 50 mm, Felica: 30 mm
* RF read range will vary depending on the installation environment. |
|
|
General |
CPU |
1.2 GHz Quad Core |
|
Memory |
2GB Flash + 256 MB RAM |
|
|
LCD type |
2” color TFT LCD |
|
|
LCD resolution |
220 x 176 pixels |
|
|
Sound |
16-bit Hi-Fi |
|
|
Operating temperature |
-20°C ~ 50°C |
|
|
Storage temperature |
-40°C ~ 70°C |
|
|
Operating humidity |
0% ~ 80%, non-condensing |
|
|
Storage humidity |
0% ~ 90%, non-condensing |
|
|
Dimension (W x H x D) |
71 mm x 201 mm x 44 mm (Bottom) / 34 mm (Top) |
|
|
Weight |
Device: 280g |
|
|
Bracket: 61g (Including washer and bolt) |
||
|
Certificates |
CE, FCC, KC, RoHS, REACH, WEEE |
|
|
Fingerprint |
Image dimension |
272 x 320 pixels |
|
Image bit depth |
8bit, 256 grayscale |
|
|
Resolution |
500 dpi |
|
|
Template |
SUPREMA / ISO 19794-2 / ANSI 378 |
|
|
Extractor / Matcher |
MINEX certified and compliant |
|
|
LFD |
Supported |
|
|
Capacity |
Max. User (1:1) |
500,000 |
|
Max. User (1:N) |
100,000 |
|
|
Max. Template (1:1) |
1,000,000 (Two templates per finger) |
|
|
Max. Template (1:N) |
200,000 (Two templates per finger) |
|
|
Max. Text Log |
1,000,000 |
|
|
Interface |
Ethernet |
Supported (10/100 Mbps, auto MDI/MDI-X) |
|
RS-485 |
1ch Host or Slave (Selectable) |
|
|
Wiegand |
1ch Input or Output (Selectable) |
|
|
TTL input |
2ch Input |
|
|
Relay |
1 Relay |
|
|
Tamper |
Supported |
|
|
Electrical |
Power |
Voltage: DC 12V |
|
Switch input VIH |
Min. 4V |
|
|
Switch input VIL |
Max. 1V |
|
|
Switch Pull-up resistance |
4.7kΩ (The input ports are pulled up with 4.7kΩ.) |
|
|
Wiegand output VOH |
Min. 4V |
|
|
Wiegand output VOL |
Max. 1V |
|
|
Wiegand output Pull-up resistance |
Internally pulled up with 1 kΩ |
|
|
Relay |
Voltage: Max. 30VDC |
|
|
Platform |
BioStar 2 |
Supported |
|
BioStar 1 |
Supported |
