SPECIFICATIONS
|
Category |
Feature |
Specification |
|
XPD2-MDB |
||
|
Credential |
LF card option |
EM |
|
HF card option |
MIFARE, MIFARE Plus, DESFire/EV1, FeliCa |
|
|
NFC card |
Supported |
|
|
BLE card |
Supported |
|
|
RF read range* |
MIFARE/DESFire/EM : 50 mm, FeliCa: 30 mm
* RF read range will vary depending on the installation environment. |
|
|
General |
CPU |
80 MHz |
|
Memory |
256 KB Flash + 64 KB RAM |
|
|
LED |
Multi-color |
|
|
Sound |
Multi-tone Buzzer |
|
|
Operating temperature |
-35°C ~ 65°C |
|
|
Storage temperature |
-40°C ~ 70°C |
|
|
Operating humidity |
0% ~ 95%, non-condensing |
|
|
Storage humidity |
0% ~ 95%, non-condensing |
|
|
Dimension (W x H x D) |
48 mm x 144.7 mm x 27 mm |
|
|
Weight |
Device: 117g |
|
|
Bracket: 30g (Including washer and bolt) |
||
|
IP rating |
IP65, IP67 |
|
|
IK rating |
IK08 |
|
|
Certificates |
CE, FCC, KC, RoHS, REACH, WEEE, SIG |
|
|
Interface |
RS-485 |
1ch |
|
Wiegand |
1ch |
|
|
LED |
2ch |
|
|
Beep |
1ch |
|
|
Tamper |
Supported |
|
|
Electrical |
Power |
Voltage: DC 12 V, Current: Max. 400 mA |
|
Switch input VIH |
Min. 3V |
|
|
Switch input VIL |
Max. 1V |
|
|
Switch Pull-up resistance |
4.7kΩ (The input ports are pulled up with 4.7kΩ.) |
|
|
Wiegand output VOH |
More than 4.8V |
|
|
Wiegand output VOL |
Less than 0.2V |
|
|
Wiegand output Pull-up resistance |
Internally pulled up with 1 kΩ |
|
|
Platform |
BioStar 2 |
Supported |
|
BioStar 1 |
Not Supported |
