SPECIFICATIONS
General |
RF Option |
XSE: 125kHz EM |
XSM: 13.56MHz MIFARE, MIFARE Plus, DESFire/EV1 (CSN) |
||
Certificates |
CE, FCC, KC, RoHS |
|
Capacity |
Max. User (1:1) |
200,000 |
Max. User (1:N) |
200,000 |
|
Max. Text Log |
1,000,000 |
|
Max. Image Log |
5,000 |
|
Interface |
TCP/IP |
Yes |
RS-485 |
1ch |
|
Wiegand |
1ch In and 1ch Out |
|
Input |
2 Inputs |
|
Relay |
1 Relay |
|
Mechanical |
CPU |
667MHz DSP |
Memory |
128MB RAM + 1GB Flash |
|
LCD |
3.5” Color Touch |
|
Sound |
16-bit Hi-Fi |
|
Operating Temp. |
-20° to 50°C |
|
Tamper |
Yes |
|
Dimensions |
79 x 135 x 21 (WxHxD mm) |
|
Electrical |
Power |
Min. 10.8 VDC Typ. 12 VDC Max. 13.2 VDC |
Consumption |
Max. 360 mA |
|
Switch Input VIH |
Min. 3.5 V Max. 10.0 V |
|
Switch Input VIL |
Max. 2.0 V |
|
Switch Pull-up Resistor |
4.7 k? (The input ports are pulled up with 4.7k? resistors.) |
|
Wiegand Output VOH |
5 V |
|
Wiegand Output VOL |
0.8 V |
|
Wiegand Output Pull-up Resistor |
4.7 k? |
|
Relay |
Form C Relay Voltage: Max. 24 VDC Current: Typ. 0.5 A, Max. 1 A |
|
Platform |
BioStar 1 |
Supported |
