Specifications
Model Name |
XS2-DPB |
XS2-QDPB |
XS2-APB |
XS2-QAPB |
|
RFID |
RF Option |
125 kHz EM & 13.56 MHz MIFARE, |
125 kHz EM, HID Prox & 13.56 MHz MIFARE, |
||
MIFARE Plus, |
MIFARE Plus,DESFire EV1/EV21), |
||||
DESFire EV1/EV21), FeliCa |
FeliCa, iCLASS SE/SR/Seos |
||||
Mobile Card |
NFC, BLE |
||||
QR/Barcode |
N/A |
Supported2) |
N/A |
Supported2) |
|
HW |
CPU |
1.5 GHz Quad Core |
|||
Memory |
16 GB Flash + 1 GB RAM |
||||
Max. User |
500,000 |
||||
Max. Logs |
Text 5,000,000 / Image 50,000 |
||||
LCD |
4" IPS color LCD / 480 x 800 pixels |
||||
Camera |
CMOS 2M pixels / 1600 x 1200 |
||||
Operating temperature |
20°C–50°C (-4°F–122°F) |
||||
Dimensions (WxHxD, mm) |
82 mm x 159 mm |
82 mm x 203 mm |
82 mm x 159 mm |
82 mm x 203 mm |
|
x 25.9 mm |
x 33.9 mm |
x 25.9 mm |
x 33.9 mm |
||
Tamper |
Supported |
||||
Certificates |
KC, CE, FCC (Compliance: RoHS, REACH, WEEE) |
||||
Interface |
Ethernet |
Supported (10/100 Mbps, auto MDI/MDI-X) |
|||
RS-485 |
1 ch Host or Slave (Selectable) |
||||
Wiegand |
1 ch Input or Output (Selectable) |
||||
TTL |
2 ch Inputs |
||||
Relay |
1 Relay |
||||
USB |
USB 2.0 (Host) |
||||
PoE |
Supported (IEEE 802.3af compliant) |
||||
IP rating |
IP65 |
||||
Electrical |
Power |
DC 12 V (Max. 0.8 A) or DC 24 V (Max. 0.45 A) |
